5530553-4

AMP5530553-4
Heilind Number:AMP5530553-4
Manufacturer:TE Connectivity
Manufacturer Number:5530553-4
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

T/SPRING STMPD

More >>

Specifications

AttributeValue
Product Category:
Pin & Socket Housings & Contacts Pin & Socket Contacts
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 5530553-4
Amperage:3 A
Gender:Female
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Contact Material:Phosphor Bronze
Contact Plating:Gold
Contact Type:Socket
Package Quantity:15000
Contact Amperage:3 A
Insulation Resistance:5000 MΩ
GPL:401
Packaging:Reel
Operating Temperature Range:-40 - 185 °F, -40 - 85 °C, -65 - 105 °C, -85 - 221 °F
Circuit Application:Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:30 - 30 µin, .762 µm
PCB Retention:Without
PCB Contact Termination Area Plating:Tin
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Wire & Cable
Product Code:G898
Wire Size:.12 - .4 mm², 22 - 26 AWG
Connector System:Cable-to-Cable
ECCN:EAR99
Applied_Pressure:Standard
Wire Insulation Support:With
Accepts Wire Insulation Diameter:.035 - .054 in, .91 - 1.37 mm
PCB Contact Termination Area Plating Thickness:1.27 µm, 50 µin
Contact Orientation:Straight
Contact Retention Type in Housing:Crimp Snap-In
Part Aliases:5530553-4
SKU:AMP5530553-4

Detailed Description

Elevate your connectivity with our meticulously crafted T/SPRING STMPD socket contact, designed for seamless integration in female cable mount applications. A testament to precision engineering, this contact boasts a gold-plated phosphor bronze construction, ensuring optimal signal transmission with a contact amperage of 3A. With a package quantity of 15000, it's ideal for high-volume projects, while its crimp termination method guarantees secure and efficient assembly. Operating flawlessly in temperatures ranging from -65 to 105°C, this contact is a reliable companion for various signal circuit applications. RoHS compliant and boasting a 5000 MΩ insulation resistance, it meets stringent quality standards. Trust in its performance for your cable-to-cable connector setups, where its straight orientation and crimp snap-in retention type provide ease of use. Embrace the future of connectivity with this essential component.
