41832

AMP41832
Heilind Number:AMP41832
Manufacturer:TE Connectivity
Manufacturer Number:41832
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FASTON 250 (6.3 MM) REC 18-14 AWG TPBR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 41832
Series:FASTON 250
Contact Material:Brass
Contact Plating:Tin
Overall Length:19.05 mm, .75 in
Material:Brass
Compatible Tab Width:.25 in, 6.35 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:14 - 18 AWG, .82 - 2.08 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.12 - .17 in, 3.1 - 4.3 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP41832
Fully Insulated:No
Connection Capacity:Single
Receptacle Terminal Stock Thickness:.43 mm / .017 in
UL Rating:Listed
CSA Certified:Yes
Mating Retention Type:Dimple
Wire Insulation Support:With
Line:Premier
Wire/Cable Type:Regular Wire
Insertion Force:Normal
Sealable:No
Insulated:No
Terminates To:Wire & Cable

Detailed Description

Enhance your electrical connections with our FASTON 250 series receptacle terminals. Designed for seamless integration, these straight-oriented connectors feature a reliable brass construction with a durable tin plating, ensuring optimal conductivity and corrosion resistance. Suitable for 18-14 AWG wires, they offer a secure F-crimp attachment method for easy installation. With an operating temperature range of -40 to 110°C (-40 to 230°F), they are ideal for various industrial and automotive applications. Trust in the quality and compliance of our RoHS-certified product to meet your connectivity needs with efficiency and precision. Elevate your wire termination experience with these high-performance receptacle terminals.
